Form Factor: M.2 2280
Interface: PCI-Express 4.0×4, NVMe 1.3
Total Capacity: 2000GB*
Sequential Read Speed : up to 5000 MB/s**
Sequential Write speed : up to 4400 MB/s**
Wear Leveling, Over-Provision technologies
TRIM & S.M.A.R.T supported
Fully Body Copper Heat Spreader
Warranty: Limited 5-years
nterface PCI-Express 4.0×4, NVMe 1.3
Form Factor M.2 2280
Total Capacity 2000GB
Warranty Limited 5-years or 3600TBW
NAND 3D TLC Toshiba BiCS4
External DDR Cache DDR4 2GB
Sequential Read speed Up to 5000 MB/s
Sequential Write speed Up to 4400 MB/s
Random Read IOPS up to 750k
Random Write IOPS up to 700k
Dimension (W x H x L) 80.5 x 11.4 x 23.5 mm
Mean time between failure (MTBF) 1.77 million hours
Power Consumption (Active) Average: R : 6.5W; W : 6.6W
Power Consumption (Idle) 21.1mw
Temperature (Operating) 0°C to 70°C
Temperature (Storage) -40°C to 85°C
